According to customer ventilation requirements, the aluminum perforated access floor is manufactured from a bare aluminum panel and achieves ventilation rates from 15% to 30% through precisely sized perforations, while maintaining the original performance characteristics of the solid aluminum panel; it is suitable for telecom exchange rooms, data centers, computer rooms, electrical switch rooms, and dust-free factories.
| Item Code | Size (mm) | Concentrated Load | Impact Load (N) | Ultimate Load (N) | Uniform Load (N) | Rolling Load | ||
|---|---|---|---|---|---|---|---|---|
| N | Kg | 10 Times | 10000 Times | |||||
| LP-QL-A | 600*600*55 | ≥ 5560 | ≥ 567 | ≥ 780 | ≥ 16680 | ≥ 33000 | 5560 | 4450 |
| LP-QL-B | ≥ 6675 | ≥ 670 | ≥ 1005 | ≥ 19892 | ≥ 34500 | 6675 | 5340 | |
Remark: Surface resistance value ranges from 1×10 to 1×10 Ohm.FFH range from 100mm to 300mm.Other height could be customized.
* Product specifications subject to changes without prior notice
Strong stability, precise and flexible
Anti-fire, anti-water, anti-static, anti-magnetic, long product life
High loading capacity, easy to install, fully interchangeable
Contains no ferrous material to disrupt magnetic fields
100% recyclable, environment friendly
Conductive gasket ensures continuous conductivity
| Item Code | Product Name | Ventilation Coefficient | Loading Capacity (Kg) | Length (mm) | Width (mm) | Thickness (mm) | Material | Fireproof Performance |
|---|---|---|---|---|---|---|---|---|
| YP-YFL-M-55 | Plum flower type ventilated floor | 55% | 450 | 600 | 600 | 55 | Aluminum | A |
| YP-TF-G-70 | Grille type aluminum ventilation floor | 70% | 360 | 35 | ||||
| YP-TFL-G-70 | Striped aluminum ventilation floor | 150 | 70 |
